Line Post Pin Insulator

The Line Post Pin Insulator P-22-A is an Australian-standard line post model. Its rated voltage is 22 kV. The structure height is 165 mm, and the disc diameter is 230 mm. The mechanical failing load is 11 kN. This product complies with AS 1304. The "A" indicates a short-shank design. The creepage distance is 432 mm, and the dry arcing distance is 200 mm. The large disc diameter provides a longer creepage distance, which supports reliable outdoor operation. The line post design can withstand higher bending loads, making it suitable for line support and conductor fixing. We use high-quality electrical porcelain for the product body. High-pressure forming creates a dense structure and provides stable mechanical strength. This product is widely used on 22 kV overhead lines in Australia. It is also used in distribution projects in Southeast Asia.

We operate multiple automated production lines to efficiently produce high-demand models such as P-22-A. Our technical team regularly calibrates the production equipment to maintain dimensional stability over time. Our quality department conducts spot checks on each batch. We also perform electrical and mechanical performance tests according to the applicable requirements. Factory test reports include measured data for each test item. Our annual output value is approximately RMB 80 million, giving us sufficient production capacity to handle large orders. For long-term customers, we can sign framework agreements and offer prices based on annual purchase volumes. If required, we can also arrange AS-standard type tests for the product and provide complete test reports.

Delivery takes 25 to 35 days. We support mixed orders with different models. We provide free samples for quality and dimensional confirmation. We support FOB and CIF trade terms. We pack the products on fumigated wooden pallets with cartons. Each piece is placed in a separate compartment to reduce the risk of damage during transportation. Shipping marks and labels can be customized according to your requirements. The warranty period is 12 months. Our after-sales team responds within 24 hours. This Line Post Pin Insulator is a versatile and dependable option for 22 kV line post applications.

All products support custom dimensions, voltage ratings, OEM/ODM services, and manufacturing based on drawings.
