Polymer Post Insulator

The Polymer Post Insulator 57-2S/57-2L is a dual-specification post insulator designed for 35 kV distribution line applications. It offers two stem options, including short stem and long stem designs. The rated voltage is 35 kV, and the disc diameter is 140 mm. The mechanical failing load reaches 12.5 kN. The product complies with ANSI C29.7 requirements.

The creepage distance is 559 mm, and the dry arcing distance is 241 mm. The short stem version (S type) has a structure height of 290 mm, while the long stem version (L type) has a structure height of 360 mm. Different stem heights allow customers to select a suitable insulation distance according to pole design and installation conditions.

The porcelain body is produced with controlled forming and firing processes. The dense structure provides stable mechanical strength and reliable electrical insulation performance during outdoor operation.

This Polymer Post Insulator is mainly used on 35 kV distribution lines, including straight poles and tension poles. The dual-specification design provides more flexibility for different line structures and installation requirements.

We produce both S type and L type models under the same production system. The shared production process helps maintain consistent quality between different stem options.

Our manufacturing team controls key steps such as porcelain forming, glazing, and high-temperature firing. These processes help keep product dimensions stable during mass production. The quality department checks important parameters, including structure height, insulation distance, and mechanical performance.

Before shipment, we perform power frequency withstand tests and mechanical load tests on production batches. These inspections verify electrical safety and mechanical reliability.

Our technical team can recommend suitable stem options based on installation conditions, including pole structure and required insulation distance. The product has been supplied for overseas distribution projects where different installation environments require flexible product selection.

The normal delivery period is 25 to 35 days. Customers can combine short stem and long stem models in one order according to project requirements.

We provide samples for testing and product confirmation before bulk production. Products are packed on export wooden pallets with cartons. Different specifications are separated and clearly marked to simplify receiving and installation work.

FOB and CIF shipping terms are available. The warranty period is 12 months after delivery.

The Polymer Post Insulator provides a practical solution for 35 kV distribution networks that need different mounting heights with stable insulation performance.

All products support custom dimensions, voltage ratings, OEM/ODM services, and manufacturing based on drawings.
